RD-DH32
Fully enclosed design, easy  paper loading structure, unique patented technology of lock  control device, which can effectively prevent the paper door from being opened accidentally, effectively protecting the safe and reliable work of the printer
Hotline:4000-850-880

Product specification

printing method

thermal line printing

Printing speed

50mm/sMAX

Resolution ration

203dpi(8dots per millimeter ), 384dots per line

Effective print width

48mm

Paper feed step

0.125mm

Foreign language characters

1.Support standard ASCII characters (96): 5×7

2.Support extended ASCII characters (352): 6×8

3. Support the User-defined character: 6×8.

Chinese characters

Equip with GB2312 of 24×24 dot array(user option:16×16 dot array or 12×12dot array)

lack of paper detection

Yes

Out Interface

1.standard parallel interface(P): 26 wire double row needle

2.Standard serial interface (S): 10 wire double row needleRS232 or TTLor 5PIN white base (RS232&TTL)

3.485interface (S5):10 wire double row needleRS232 or TTLor 5PIN white base (RS232&TTL)

buffer

32k

instruction system

print command: ESC/P (Compatible with IBM/EPSON and ESC/P)

Print drivers

WIN2000/NT/XPparallel interface \serial interfacedrive

operating voltage

DC8.5V±5%4A

working current

greater than 3Apower consumption can be adjusted according to customer requirements.

print head life

50km

Paper type

Ordinary thermal Paper (width: 58±0.5mmø33mm)

paper loading way

easy paper loading

Cut type

tearing paper manually

Operating temperature / humidity

055/1080%RH(RH)

Storage temperature / humidity

2060/1090%RH(RH)

weight(include print paper)

approximately 180g

Installation dimension (mm)

103 x 57 (WH)

outline dimension (mm)

114x70x64 (WHD)


Related accessories

1

Data download

  • RD-DH Manual
    1331405kb
    21Second

Application area

Mobile PrintingInstrumentsPowerEquipmentsFirefighting
