Printing performance

printing method

thermal line printing

Printing speed

60mm/s

Resolution ration

8dots per millimeter ,384 dots per line

Effective

print width

48mm

The number of characters per line

32

printing    characters

448 characters and blocks including

▲96 ASCII characters,

▲352 Greek, German, Russian, French and other letters, Japanese Katakana, some Chinese characters, number symbols, printed characters, block icons

▲32 user-defined characters

There are 8178 Chinese characters and foreign language words and blocks in the GB2312 font

Chinese characters

Equip with the GB2312 font

Character size

foreign language: 5×7

Block icons: 6×8

User-defined character: 6×8

Chinese characters: 24×24/16×16/ 12×12

Detection function

lack of paper detection

yes

Paper type

Thermal paper: width 57mm±0.5mm, ø30～50mm

Interface parameters

standard parallel interface, Standard serial interface, 485 interface, USB interface

control system

buffer

32K

instruction system

print command: ESC/POS (Compatible with IBM/EPSON and ESC/P)

Print drivers

WIN98/NT/XP/2K

power supply

  operating voltage

DC5V～7.5V

Operating current

4A

reliability

MCBF：five million lines

Loading paper way

Mechanical loading paper structure

Physical characteristics

Operating

environment

Temperature: 0～50℃

Humidity: 10～80%(RH)

Storage temperature / humidity

Temperature: -20～60℃

Humidity: 10～90%(RH)

bare machine

weight

approximately 296g（ excluding printing paper）

outline dimension (mm)

160×106×40 (LⅹWⅹ H)
