◇Meet the different needs for the medium width range of 16ｍｍ－82ｍｍ
◇Print head pressure is adjustable
◇Have the automatic calibration function for paper
◇Printer themselves can adapt to the environment temperature control
◇modular design, meet different application requirements
|
printing method |
thermal line printing |
|
Resolution ration |
203DPI |
|
print width |
16-82mm |
|
Printing speed |
127mm/s (MAX) |
|
buffer |
DRAM: 4M FLASH: 4M |
|
The print head temperature detection |
inches switch |
|
Detector for paper |
Photoelectric sensors |
|
communication interface |
USB interface/ parallel interface / serial interface / Network port |
|
bar code / characters / graphics |
Bar code: CODE128、EAN128、ITF、CODE39、CODE93、EAN13、 EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、 CODABAR、POSTNET、UPC-A、UPCA+2、UPCA+5、 UPC-E、UPCE+2、UPC-E+5、CPOST、MSI、MSIC、 PLESSEY、ITF14、EAN14、QRCODE、PDF417 |
|
Characters set: Common single-byte fonts：FONT 0--FONT 8 |
|
|
Monochrome PCX, BMP and other image files can be downloaded to FLASH, DRAM |
|
|
Paper type |
thermal roll paper/ adhesive paper etc. |
|
medium width |
16mm～82mm |
|
Roll paper external diameter |
100mm (MAX) |
|
Roll paper internal diameter |
25mm (MIN) |
|
Out of paper method |
Tear |
|
buffer |
128K/ NV Flash 256k bytes |
|
Operating system |
Support Linux/Windows 7 System Driver and a variety of international languages! |
|
power supply |
24VDC, 2.5A |
|
weight |
约1.35kg |
|
outline dimension (mm) |
212.5(D) x 145(W) x 145(H)mm |
|
Operating environment |
5～45℃, 20－80%RH（no condensation） |
|
Storage environment |
－40～55℃，≤93%RH（40℃） |
|
|
|
